Sink – DB740X430X220R10U

Model : DB740X430X220R10U
Installation Type : Undermount
Dimension : 740x430x220MM
Cut out size : 710x400MM
Bowl 1 Dimension : 340x400x220MM
Bowl 2 Dimension : 340x400x220MM
Waste Outlet : 90/97/98/110/123MM
Material : SS AISI304
Thickness : 1.2MM
Surface : Hairline
Other : Overflow Hole



Drawing
