SINK – SI860R15U

Model : SI860R15U
Installation Type : Undermount
Dimension : 860x440x200MM
Cut out size : 820x395MM
Bowl 1 Dimension :395x395x200MM
Bowl 2 Dimension : 395x395x200MM
Waste Outlet :90/97/98/110MM
Material : SS AISI304
Thickness :0.8MM
Surface : Hairline
Other : Overflow Hole /No Tap Hole



DRAWING
