2 BOWL 1-DRAINER Model :ECON3

Model :ECON3
Installation Type : Inset
Dimension : 1200x500x150-180MM
Cut out size : 1184x484MM
Bowl 1 Dimension : 358x410x150-180MM
Bowl 2 Dimension : 370x410x150-180MM
Waste Outlet : 90/98MM
Material : SS AISI201 or AISI304
Thickness : 0.5/0.6/0.8MM
Surface : Satin
Other : Tap/No Tap Hole, Overflow Hole

DRAWING (SINK)
