SINK – DB660R10U

Model : DB660R10U
Installation Type : Undermount
Dimension : 660x460x220MM
Cut out size : 658x458MM
Bowl 1 Dimension : 360x400x220MM
Bowl 2 Dimension : 200x400x220MM
Waste Outlet : 90MM
Material : SS AISI304
Thickness : 1.0MM
Surface : Hairline
Other : Overflow Hole

DRAWING (SINK)
